Vibration Measurement:
Measurement Instrument
1.Notebook, tablet PC used for measurement
2.Endevco、PCB、B&K Accelerometers
3.Analog Digital Converter: Portable Vibration Measurement System, NI-9233 Data Acquisition Module
4.Computer programs for vibration measurement
Instrument installation and measurement：
Vibration measurement and analysis program：
Noise measurement：
Measurement Instrument
Noise meter: 01dB SOLO, RION NA-27
Shaft Horsepower, Shafting Torsional Vibration Measurement
Measurement Instrument
- Computer used for Measurement
- Strain gauges
- Analog-Digital converter
- Computer program for Shaft horsepower, torsional vibration measurement
馬力量測專用程式畫面
Ship Speed, Maneuvering Performance Test
Measurement Instrument
- Computer
- D-GPS (differential global positioning system) Receiver and antenna
- Computer program “SOIC/UCTrial” for ship speed measurement
General Test Items：
Speed Test
Turning Test
Crash stop astern and forward test
Inertial Test
Ship Motion Measurement
Measurement Instrument
- Measurement computer
- Motion sensor
- Computer program for motion measurement
